Q10TIRM Dual Sensor 10x Zoom EO/IR Object Tracking LRF Camera

Description

Professional 3-axis High-precise FOC Program

The Q10TIRM camera gimbal offers exceptional stability and precision, driven by a dedicated processor, resulting in pinpoint-precise motor rotation with an impressive control accuracy of ±0.01°. Its unique mechanically limited design and concealed wires ensure stable data transmission and exceptional durability. Vibration is effectively eliminated with the help of four damping balls and a lightweight damping board, resulting in seamlessly smooth video footage. Even during high-speed flights, the 360° rotation capability of the gimbal maintains stable and smooth image capture.

10x Optical Zoom Camera

The Q10TIRM boasts an optimized 3-axis gimbal that guarantees precision motor rotation with a control accuracy of ±0.01°, powered by a dedicated processor. This feature allows for a continuous 360° rotation of the gimbal, ensuring stable and smooth video footage, even during high-speed flights.

IR+EO Dual Sensors Object Tracking

The Q10TIRM incorporates advanced object tracking capabilities with built-in normalization, cross-correlation, and tracking algorithms, enhanced by an object missing recapture algorithm for stable target tracking. It supports customizable user OSD characters, adaptive gates, cross cursors, and trace information display. With a tracking speed of up to 32 pixels per frame and an object size range from 16×16 pixels to 160×160 pixels, the tracking accuracy is significantly improved. The minimal signal-to-noise ratio (SNR) of 4db and the mean square root values of pulse noise in the object position (<0.5 pixel) further enhance tracking precision.

GPS Location Resolving

Using an advanced location calculating algorithm, the Q10TIRM accurately calculates the distance of objects within a range of 3000 meters, providing precise analysis of object longitude and latitude. This feature proves invaluable in military and police enforcement operations.

Multi Output Methods Optional

The Q10TIRM pro offers versatile output options, including HDMI, Ethernet/IP, and SDI outputs. HDMI and Ethernet outputs support 1080p, while the default Ethernet output resolution is 720p with recording capabilities at 1080p. The IP and SDI output versions feature 360-degree endless pan.



Multi Control Methods

The camera gimbal supports default PWM and Serial port TTL control, with optional SBUS compatibility. For IP output versions, TCP control via an Ethernet cable is also available.

Control box signal interfaces:

Compatible with Viewport

The Q30TIRM pro is designed to be compatible with Viewpro’s quick-release connector, Viewport, offering easy assembly and plug-and-play functionality.

Dimensions

 Specifications

Hardware Parameters
Working voltage	12V
Input voltage	3S ~ 6S
Dynamic current	1100mA @ 12V
Idle current	950mA @ 12V
Power consumption	≤ 6.6W
Working environment temp.	-20℃ ~ +60℃
Output	micro HDMI(1080P 60fps) / IP (720p)
Local-storage	SD card (Up to 128G, class 10, FAT32 or ex FAT format)
Control method	PWM/S.BUS/TTL/TCP( IP output)
Gimbal Spec
Angle range of structure design	Pitch/Tilt: -50°～105°,      Roll: ±60°,    Yaw/Pan: ±300° / ±360°*N (IP output version)
Angle range of software design	Pitch/Tilt: -45°～90°,   Yaw/Pan: ±290° / ±360°*N (IP output version)
Yaw/Pan	±170° / ±360°*N (IP/SDI/Skyport Output)
Vibration angle	Pitch/Roll: ±0.02°, Yaw：±0.02°
One-key to center	√
Camera Spec
Imager Sensor	1/3″ Panasonic CMOS Sensor
Picture quality	Full HD 1080 (1920*1080)
Effective pixel	2.48MP
Lens optical zoom	10x, F=5.1~51mm
Angle of View (D, H, V)	D:  68°(Wide end) ~ 6.7° (Tele end)
	H: 54°(wide end) ~ 4.9°(tele end)
	V: 31°(wide end) ~ 4.0°(tele end)
Photo storage format	JPG(1920*1080/1280*720)
Video storage format	MP4  (1080P/720P 25fps/30fps)
Sync system	Progressive scanning
S/N ratio	more than 50dB
Min illumination	Color : 0.5 lux , BW : 0.1lux; Color DSS : 0.125 lux , BW DSS : 0.025 lux
Illumination range	100 lx ~100,000 lx
Gain Control (AGC)	Off / On
White balance	Auto / One Push / Manual / Indoor / Outdoor
Shutter speed	1/30(25) ~ 1/30,000 sec
Exposure	Mode / AGC / Shut Speed / Iris / DSS / Flickerless / Brightness / WDR/BLC / D&N
Defog	Yes
OSD	Yes
Camera Object Tracking
Update rate of deviation pixel	50Hz
Output delay of deviation pixel	5ms
Minimum object contrast	5%
SNR	4
Minimum object size	32*32 pixel
Maximum object size	128*128pixel
Tracking speed	±32 pixel/frame
Object memory time	100 frames (4s)
The mean square root values of pulse noise in the object position	< 0.5 pixel
Thermal imager spec
Lens size	25mm
Horizontal FOV	24.6°
Vertical FOV	18.5°
Diagonal FOV	30.4°
Detective Distance (Man: 1.8×0.5m)	735 meters
Recognize Distance (Man: 1.8×0.5m)	184 meters
Verified Distance (Man: 1.8×0.5m)	92 meters
Detective Distance (Car: 4.2×1.8m)	2255 meters
Recognize Distance (Car: 4.2×1.8m)	564 meters
Verified Distance (Car: 4.2×1.8m)	282 meters
Working mode	Uncooled long wave (8μm~14μm) thermal imager
Detector pixel	640*480
Pixel size	17μm
Focusing method	Athermal prime lens
Emissivity correction	0.01~1
NETD	≤60mK (@25℃)
MRTD	≤650mK (@characteristic frequency)
Image enhancement	Auto adjust image brightness and contrast ratio
Color palette	Gray Scale, pseudo color, Iron Oxide Red, Rainbow, Color
Auto Non-uniform correction	Yes (no shutter)
Digital zoom	1x~4x
Sync correct time	Yes
Thermometry type	Temperature bar (psudo color display) max temp, min temp, FOV center temp (Optional)
Temperature warning	0℃~120℃(For thermometry version only)
Thermal Object Tracking
Update rate of deviation pixel	50Hz
Output delay of deviation pixel	5ms
Minimum object size	32*32 pixel
Maximum object size	128*128 pixel
Tracking speed	±32 pixel/frame
Object memory time	100 frames (4s)
Laser Rangefinder
Range	3000 meters
Resolution	0.5m
Working current:	80mA （max）
Light Beam	905nm pulse laser
Divergent Angle	3 mrad
Laser pulse frequency	1HZ
Power	＜ 1 mW (safe for eye)
Ranging mode	Pulse
Location Resolving	Latitude and longitude of target
Ranefinder	Target distance measuring
Packing Information
N.W.	716g
Product meas.	260*180*280mm
